P/I-P55SP4 User's Manual
Since we are assuming that your mainboard is already installed
in a system, it was most likely set up by your system dealer accord­
ing to the design specifications of your computer. This could mean
that your mainboard's current settings are not the same as the de­
faults shown in this manual. Your system manual may have addi­
tional information on how the mainboard should be set up.
If you want to change the existing configuration, consult all of
your system documentation. Also be certain that opening up and
working on the system yourself won't violate your system warranty.
Most system vendors do allow you to open the system to install ex­
pansion cards or additional peripheral equipment.
This manual provides all the information you need to upgrade
or change the setup of the board. If you don't feel confident of your
ability to work on the computer yourself, ask your dealer or a quali­
fied technician to do it for you.
Main Features
The P/I-P55SP4 has many performance and system features in­
tegrated onto the mainboard, including the following:
• Supports 75, 90, 100, 120, 133 or 150MHz P54C/CS/CQS
Pentium CPUs in a ZIP (Zero Insertion Force) Socket 5 or 150
and 167MHz P55C Pentium CPUs in a ZIF Socket 7.
• SIS 551X chipset
• Uses 72-pin SIMM DRAM modules of 1MB to 128MB in mul­
tiple configurations up to 512MB, with support for both Fast
Page Mode and Extended Data Output (EDO) SIMMs.
• Write-back "Level 2" external static RAM cache. There are two
cache options, SRAM sockets and a cache module socket. The
sockets for individual SRAM chips allow installation of 256KB,
512KB or 1MB of Asynchronous 15ns SRAM.
1 - 2
