MAINTENANCE
LUBRICATION CHART
0 SFINDLE
0 WHEEL 8EAF!I№S
0 MOWER CLUTCH PIVOT
BOTH EWOS OP
FOOTPEOALSHAFT
0SAE MOTOR OIL
0 EXTREME PRESSURE
LUaWCATIIilG grease
AMDEX N0*1, SEARS
PART NO 25S7R
0 REFER TO ENGINE OIL SPEC’S.
lUNDER INITIAL PREPARATION
IN OWNERS MANUAL!
SPINDLE ©
—-------WHEEL BEARINGS 0
.3 -^I^^I;;^ENGINE 0
CLUTCH PIVOT©
I BOTH ENDS LIFT SHAFT ©
r------------
1
/
.
^ 1 ,
REPAIR & ADJUSTMENT
NEGATIVE
(BLACK CABLE!
TERMINAL /\
20
A
BEFORE MAKING ANY INSPECTION,
ADJUSTMENT OH REPAtRs
T PUSH TRACTOR CLUTCH/BRAKE
PEDAL COMPLETELY INTO
"BRAKE" POSITION.
2. MOVE GEAR SHIFT LEVER TO "M"
NEUTRAL POSITION,
3. PLACE PARKING BRAKE IN "EN­
GAGED" POSmON. REMOVE
FOOT FROM PEDAL.
4. PLACE ATTACHMENT CLUTCH
LEVER IN "DISENGAGED” POSI­
TION.
5. TURN IGNITION KEY TO "OFP
POSITION. SHUT OFF THE EN­
GINE.
S. MAKE ABSOLUTELY SURE THE
SLADE AND ALL MOVING PARTS
HAVE COMPLETELY STOPPED.
7, REMOVE THE IGNITION KEY.
a. DISCONNECT THE SPARK PLUG
WIRES FROM THE SPARK PLUGS
AND KEEP WIRES AWAY FROM
THE PLUGS TO PREVENT INJURY
FROM ACCIDENTAL STARTING.
BE CAREFUL TO AVOID TOUCH­
ING HOT ENGINE OR MUFFLER
COMPONENTS.
