PARTS LIST FOR CRAFTSMAIS! 12-INCH MOTORIZED TABLE SAW
MODEL NUMBER 113.242502
ANY ATTEMPT TO REPAIR THIS MOTOR MAY
CREATE A HAZARD UNLESS REPAIR IS DONE
FIGURE 4 - 62743 MOTOR ASSEMBLY
Key
No,
Part
No
Description
_
62743
Complete Motor Assembly
1
63798
Panel, Mounting
2
62245
Relay
3
62407
Protector
4
STD 376116
Capacitor
5
62749
Box Assembly. Pane!
w/ Nameplate
6
STD B00603
Screw, Pan Hd* Self-Tapping
N0,6-32x3/8
7
63467
Cap, Flag Terminal
8
62265
Lead Assembly, Red 3" Long
9
62268
Lead Assembly, Red
5-1/2" Long
t o
37908
Housing, Brake Coil
Key
No.
Part
No
Description
1 1
63133
Coil, Brake
1 2
63134
Shoe, Brake
13
63137
Lining, Brake
14
o / OO^
Disc, Brake
15
STD 600803
*Screw, Self-Tapping,
No S-32x 5/16", Pan Hd
16
63309
Cover, Brake
I j
oUboz
Cap, Shaft
18
37158
Ring, Retaining, 5/8"
19
37886
Washer, Spring
2 0
37412
CIsst
2 1
37415
Spring
2 2
30767
Washer, Spacer (As Required)
^Standard Hardware Item — May be Purchased Locadv-
