PARTS LIST FOR CRAFTSMAN 16’ .TRIABLE SPEED SCROLL SAW
MODEL NO. 113.236150
Always Order By Part Number-Not By Key Number
Key
No.
Part No. Description
1 820733 Rod, Blade Change
2 820333 Wrench, ‘T’ Handle, 4mm
3 822426-1 Housing (Includes Key #4 & 41)
4 820376-2 Screw Pan Hd Ty "TT' M4 x 0.7-28
5 821673 Table
6 813249-131 Pin, Roll M5 X 25
7 821701 Screw. Support
8 821708 Guide, Drawer
9 821707 Drawer
10 STD852005 * Lockwasher, M5
11 821389 Screw, Pan Hd M5 x 0.8-8
12 821702 Support, Scale
13 STD851006 * Washer, 6mm
14 821697 Knob
15 820322 Brush
16 820324 Cap, Brush
17 822428 • Motor
18 821712 Cord with Plug
19 821985 Housing, Control (includes label)
20 821675 Knob
21 821720 Gasket
22 819293 Grommet
23 821719 Board, Controlier
24 821672 Cover, Switch Box
25 817450-5 Screw, Pan Hd Self Tap M4 x 18
26 821722 Indicator, Tilt
27 821677 Base (Includes Labels)
28 821151-1 Screw Hex Hd M5 x 0.8-15
29 820249-1 Screw Hex Hd M6 x 1.0-20
30 STD852006 * Lockwasher, M6
31 821683 Support, Hold Down
32 821697-1 Knob
* standard hardware item - may be purchased locally,
t Stock item - may be secured through the Hardware department
of most Sears Retail Stores
Key
No.
Part No. Description
33 821690 Support, Plate
34 821692 Spring, Hold Down
35 821693 Guard, Blade
36 821691 Clamp, Hold Down
37 818471-6 Screw, Hex Soc Set,M5 x 0.8-5
38 821689 Support Bar
39 821716 Plate Clip
40 820379-1 Screw, Hex Soc Cap, M5 x 0.8-8
41 821717 Bearing, Flanged
42 821704 Bolt, Tension
43 816018 Wedge, Tension
44 816017 Nut, Tension
45 821675-1 Knob
46 821666 Arm, Upper
47 66061 Spring
48 821668 Arm, Lower
49 818468 Bearing, Ball 625ZZ
50 818469 Screw, Hex Soc Cap, M5 x 0.8-16
51 817450-1 Screw, Pan Hd Self Tap M4 x 16-8
52 46-58600-3 * Washer, 4.2 x 10x0.9
53 821706 Link. Arm
54 813249-127 Pin, Roll M5x 14
55 820317 Clamp, Lower Blade
56 818471 Screw, Hex Soc Set. M6 x 1.0-6
57 821709 Coupling, Eccentric
58 820314 Holder, Lower Blade
59 9-26877 t Blade, Scroll Saw
60 820316 Clamp, Upper Blade
61 819248-1 Hose
62 821703 Bellows
63 820315 Holder, Upper Blade
—
SP 5641 Owner’s Manual (Not Illustrated)
5
B>
Any attempt to repair this motor may create a hazard unless
repair is done by a qualified service technician. Repair service
is available at your nearest Sears store.
