WEIGHT RESISTANCE CHART
The chart below shows the approximate weight resistance at each exercise station. “Top” refers to the 6 lb. top
weight. The other numbers refer to the 12.5 lb. weight plates. Weight resistance shown for the butterfly arm sta­
tion is for each arm.
Note: The actual resistance at each station may vary due to differences in individual
weight plates as well as friction between the cables, pulleys, and weight guides.
WEIGHT HIGH
PULUEY
(lbs.)
BUTTER­
FLY ARM
(lbs.)
PRESS
ARM
(lbs,)
LEG
LEVER
(lbs.)
LOW
PULLEY
(lbs.)
LEG
PRESS
(lbs.)
AB
STATION
(lbs.)
Top 15 26 35 34 29 27 25
1 30 35 60 44 47 58 40
2 44 45 80 62 59 89 54
3 60 54 105 77 75 110 70
4 74 63 125 102 88 147 80
5 87 77 150 111 100 183 94
6 99 82 178 125 120 208 109
7 115 90 200 147 132 238 129
8 129 112 215 172 152 263 155
9 - - 245 - - 296 -
10 - - 260 - - 327 -
