Table 4 — Compressors
KEY NO
VENDOR MODEL
OiL CHARGE (02 ± 1)
\ir\\
TC
RLA
LRA
RUN
NO
Dry
Recharge
CAPACITOR
Matsushita
MA-1
2K25S3R236A-6A
14 5
125
230/208
74
42 0
RC-4
MA-2
2K32S3R236A-6A
14 5
125
230/208
96
52 0
RC-6
Mitsubishi
MI-1
RH421SS
10 1
9 1
200
FLA
4 5
26 0
RC-12
MI-2
RH427SS
19 2
17 3
200
56
30 0
RC-8
MI-3
RH434SS
180
16 2
200
73
38 0
RC-8
MI-4
NH455NB
28 7
25 8
200
97
47 0
RC-7
Tecumseh
H-1
RK5513E
11 8
9 1
115
11 4
67 0
RC-9
Toshiba
T-1
ERH62XA3-1K
7 4
67
115
52
35 0
RC-3
T-2
ERH68XA3-1K
7 4
67
115
59
35 0
RC-3
T-3
EH88X1-1CU1
7 4
67
115
75
41 0
RC-3
T-4
PRH94XA4-4K
74
6 7
240/220
34
20 0
RC-1
T-5
PRH88XA4-3K
7 4
67
230/208
39
25 0
RC-1
T-6
PH112X2-4KU
11 0
9 9
240/220
40
23 0
RC-2
T-7
ERH88XA4-1K
7 4
67
115
7 7
43 0
RC-2
T-8
EH120X2-1KU
10 6
95
115
11 6
63 0
RC-5
T-9
PH120X2-3KU
106
95
230/208
54
33 0
RC-2
T-10
PH142X2-4KU
11 0
99
240/220
45
26 0
RC-2
T-11
PH142X2-9LU
11 0
99
200
52
27 0
RC-2
T-12
PH160X2-3LU1
14 0
126
230/208
68
38 0
RC-4
T-13
PH180X2-4LU
140
126
240/220
69
36 0
RC-4
T-14
PH210X3-3LU
20 3
18 3
230/208
9 1
49 0
RC-6
T-15
PH250X3-4LU
20 3
18 3
240/220
88
46 0
RC-6
T-16
PH250X3-9LU
20 3
18 3
200
10 2
51 0
RC-6
T-17
EH80X1-1CUI
74
67
115
—
41 0
RC-9
T-18
PH200X33-3LTU
20 3
183
230/208
—
65 0
RC-6
T-19
PH230X3J-3LTU
20 3
18 3
230/208
20 0
79 0
RC-6
T-20
PH230X3J-4LTU
20 3
18 3
240/220
—
58 0
RC-6
T-21
PH230X3-4LU
20 3
18 3
240/220
—
46 0
RC-6
T-22
PH250X3-3LU
20 3
183
230/208
—
63 0
RC-6
T-23
PH310X3-3MU
23 7
21 3
230/208
—
79 0
RC-6
T-24
PH310X3J-4MTU
23 7
21 3
240/220
-
83 0
RC-10
T-25
PH310X3-4MU
23 7
21 3
240/220
—
72 0
RC-11
FLA
“ Full Load Amps
LRA
— Locked Rotor Amps
RLA
— Rated Load Amps
Table 5 — Run Capacitors
Table 6 — Thermistor
KEY NO
CARRIER NO
MFD
VOLTS
RC-1
HC98CA016
15/5
370
RC-2
HC98CA026
25/5
370
RC-3
HC98CA027
25/7 5
370
RC-4
HC98CA036
35/5
370
RC-5
HC98CA031
30/5
370;
RC-6
HC98CA046
45/5
370
RC-7
HC98CA050
50/5
370
RC-8
HC98DA031
30/5
440
RC-9
HC98CA028
25/10
370
RC-10
HC98CA062
60/7 5
370
RC-11
HC98CA047
45/7 5
370
RC-12
HC98DA026
25/5
440
MFD
— Microfarad
KEY NO
CARRIER NO
VENDOR NO
RESISTANCE
(Ohms)
Z-1
HC95XX006
3M305C20C
25
Table 7 — Casing Dimensions (in.)
CASING
HEIGHT
WIDTH
DEPTH
104
UVe
20 Vm
17'/e
304
15S/t6
24Vm
27¥^6
404
173/i6
26
28Vi6
