19 Vent and Exhaust Lever — See Vent and

Exhaust Level in Fig 20

a Remove exhaust dooi as desci ibed under Exhaust

Door

b Rotate levei upward while pushing lever out oi

mounting slot

c Reveise above procedure for leassembly

20 Evaporator and Condenser Coils — See

Evaporatoi and Condenser Coils in Fig 24 These

coils have copper tubing The interconnecting tubing

is designed as an integral pait of the coils to make

servicing easier

21 Strainer — The strainer is installed in the inter

connecting tubing between the condenser and the
capillary tube To change the strainer
a Purge and remove all refi igei ant from the system
b Cut tubing one in from capillary tube insertion

point

c Use a thin piece of wire to remove strainer from

tubing

d Insert new strainer into tubing Reassemble with a

field-supplied 1 /4-in copper coupling

22 Test Run Unit — Plug unit into proper power

supply outlet Reiei to operating instructions in
Owner’s Handbook for Comfortable Living Check
all controls for correct operation, then unplug unit

If unit sounds noisy during test-run, it may be

because compressor spring-mount nuts have not yet

been removed See Compressor instructions (16 f)

A WARNING

Moving parts can cause personal injury Be care

ful when test-running unit Do not operate unit

with Iront grille removed

CONDENSER

'COIL

EVAPORATOR

COILi

Fig 24 — Evaporator and Condenser Coiis
