Table 4 — Fan Rpm at Motor Pulley Settings
MOTOR PULLEY TURNS OPEN
0 V2 1 IV 2 2 2V2 3 3V2 4 4V2 5
008,
009
840 815 790 765 740 715 690 665 640 615 590
012 935 910 890 865 840 815 790 765 740 715 690
014 1080 1060 1035 1015 990 970 950 930 905 885 860
f
Table 5 — Evaporator-Fan Motor Efficiency
MOTOR EFFICIENCY (%)
50LJ008-012 83
50LJ014 85
NOTE: Convert bhp to ’
„ 746 X Bhp
Watts =-^——^77T^-----
Motor Efficiency
Table 6 — Accessory Static Pressure Drop (in. wg) 50LJ008-014
COMPONENT
CFM
2200 2500 3000 3500 4000 4500 5000 5500 6000
1 Heater Module 020 030 .050 .065 .080 .100 120 140 .155
2 Heater Modules .030 .050 070 .090 .120 140 .160 190 210
Economizer .020 .020 030 040 .050 060 .070 .080 090
I
