YSI ProDSS - Manual (Page 33)

31
Operation
Figure 41 Backup Data
Figure 42 Micro USB female connector
Backup Data
→ Backup Data
A USB female to micro USB male adapter is included to directly backup
files from the handheld to a standard USB storage device. The data is
exported as a CSV file.
Enter the desired filter criteria then connect the handheld to the USB
storage device using the supplied adapter. Select Backup Data to export
the data to an USB storage device (
Figure 41 and Figure 42) .
NOTE: The USB storage device must be formatted as FAT32, not
NTFS or exFAT. The handheld will only support FAT32.
Figure 43 Delete GLP
Delete GLP
→ Delete GLP
To permanently delete the GLP file from the instrument, select Yes, then
push the
ENTER key ( Figure 43 ).
