Transmitting data MultiLab 4010-2
108 ba76142e03 08/2013
12.4 Connecting a USB memory device/USB printer
(USB-A interface (USB Host))
Connect the USB-A interface (USB Host) of the MultiLab 4010-2 to a USB flash
drive/USB printer.
Suitable USB printers:
4. Set the same transmission data at the connected instrument (PC):

Baud rate: to be selected in the range 1200 ... 19200
 Handshake: RTS/CTS
 Set at the PC only:
– Parity: none
– Data bits: 8
– Stop bits: 2
1. Connect a USB memory device/USB printer to the USB Host interface.
Model Type Paper width
Citizen CT-S281 Thermal transfer printer 58 mm
Star SP700 with USB
interface*
* Recommended printer settings for Star SP700:
- CodePage 437
- DIP switch 1...7: =ON, DIP switch 8: OFF
Details: see operating manual of your printer.
Matrix printer 76 mm
