23 | PIR Ready VT76xxW Series-Installation Guide

CONFIGURATION

PARAMETERS

DEFAULT VALUE

SIGNIFICANCE AND ADJUSTMENTS

PswrdSet
Configuration parameters
menu access password
Default value = 0
No password prompted

This parameter sets a password access to prevent
unauthorized access to the configuration menu
parameters. A default value of “0” will not prompt a
password or lock the access to the configuration
menu.
Range is: 0 to 1000

Com Addr
Terminal Equipment
Terminal Equipment Controller
networking address
Default value = 254
Range is: 0 to 254

Conditional parameter to

BACnet™ MS-TP models

(VT76xxW5x00B)
Conditional parameter to Wireless models
(VT76xxW5x00W)

This parameter will only appear when a

BACnet™ or

wireless network adapter is present. If the Terminal
Equipment Controller is installed as a stand-alone
(Network Ready) unit or with an

Echelon™ adapter, this

parameter will not be used or displayed

-For

BACnet™ MS-TP models, the valid range to is from

1 to 127. Default value of 254 disables

BACnet™

communication for the Terminal Equipment Controller.
For wireless models valid range is 0 to 254 with a
maximum of 30 Terminal Equipment Controllers per
VWG

PAN ID
Personal Area Network
Identification
Default value = 0
Range is: 0 to 1000


Conditional parameter to Wireless models
(VT76xxW5x00W)


This parameter will only appear when a wireless
network adapter is present. If the Terminal
Equipment Controller is installed as a stand-alone

(Network Ready)

unit or with a

BACnet™ or

Echelon™ adapter, this parameter will not be used or
displayed

This parameter (Personal Area Network
Identification) is used to link specific Terminal
Equipment Controllers to a single specific Viconics
wireless gateway ( VWG ) For every Terminal
Equipment Controller reporting to a gateway
( maximum of 30 Terminal Equipment Controllers per
gateway ), be sure you set the SAME PAN ID value
both at the gateway and the Terminal Equipment
Controller(s).

The default value of 0 is NOT a valid PAN ID.
