Command Operation Response Description
IN_PV_1 current pressure
XXXX mbar/
Torr/hPa
unit according to preselections
IN_PV_2 current frequency XX.X Hz pump speed
IN_PV_3 process runtime XX:XX hh:mm (hours:minutes)
IN_PV_4
LAN pressure
increase
XXX mbar/Torr/
hPa per minute pressure unit according to preselections
IN_PV_5 LAN process time XX:XX
hh:mm (VACUU•LAN: runtime of pump
since last switching of the pump)
IN_SP_1 preset pressure
XXXX mbar/
Torr/hPa
unit according to preselections
IN_SP_2 preset frequency XX:X Hz
preset pump speed,
99.9 Hz corresponds to ”HI”
IN_CFG
device set
preselections
0XXXX
1XXXX
2XXXX
4XXXX
X0XXX
X1XXX
XX0XX
XX1XX
XXX0X
XXX1X
XXXX0
XXXX1
VACUU•LAN
continuous pumping
vacuum control
RC 5 / RC 6 management
no coolant valve
coolant valve
no venting valve
venting valve
no automatic switch off
automatic switch off
remote operation off
remote operation on
IN_ERR error code
1XXX
X1XX
XX1X
XXX1
fault at pump electronics, valve, etc.
overpressure
maloperation mode pressure transducer
last command to interface incorrect
IN_STAT
status of
process control
0XXX
1XXX
X0XX
X1XX
XX00
XX01
XX02
XX03
XX10
XX11
XX20
XX21
XX22
XX23
coolant valve closed
coolant valve open
venting valve closed
venting valve open
VACUU•LAN: inactive
VACUU•LAN: pumping down,
current pressure > selected pressure
VACUU•LAN: pumping down, time for
automatic switching off is running
VACUU•LAN: system is switched off
continuous pumping: not active
continuous pumping; active
vacuum control: not active
vacuum control:
current pressure above set vacuum
vacuum control: current pressure
equals set vacuum ( ±1 Torr/mbar)
vacuum control:
current pressure below set vacuum
Read commands compatible to ”CVC 2000”
