56
Product Specifications
Model
2”
2”
2.5”
2.5”
3”
3”
Component
Individual
Shipping
Weight
Lbs
Individual
Water
Content
Gal
Prestige 250
Prestige 399
2 Boiler Manifold
3 Boiler Manifold
Hydronic Junction 4.1
7
6.6
9.3
8
167
225
267
326
124
Cascade
Kit P/N
# of
Solo
250 or 399
Boilers
Total
Input
MBH
Note 1
# of
Manifolds
Total
Output
Boiler
Horse-
Power
Minimum
Recommended
System Iron
Pipe Size
Note 5
Minimum
Recommended
Natural Gas
Header Size
Note 6
Total
Output
MBH
Note 1 & 2
Total
Net IBR
Rating
MBH
Note 3
Total
EDR
Water
Ft 2
Note 4
C(PS or RR) 500
C(PS or RR) 800
C(PS or RR)1000
C(PS or RR)1200
C(PS or RR)1600
C(PS or RR)2000 1
1
2
1
2
2 2 (250)
2 (399)
4 (250)
3 (399)
4 (399)
5(399)
2”
3”
3”
4”
4”
4” 65 - 490
112 - 798
65 - 980
112 - 1,197
112 - 1,596
112 - 1,995
446
758
892
1,138
1,518
1,897
388
659
776
990
1,320
1,650
2,588
4,396
5,176
6,603
8,804
11,006
13.3
22.6
26.6
34.0
45.3
56.7
Cascade
Kit P/N
Total
Shipping
Weight
Lbs
Total
Water
Content
Gal.
Cascade
Kit P/N
Total
Shipping
Weight
Lbs.
Total
Water
Content
Gal.
CRR 500
CRR 800
CRR 1000
CRR 1200
CRR 1600
CRR 2000 CPS 500
CPS 800
CPS 1000
CPS 1200
CPS 1600
CPS 2000 15
21
30
31
42
51 601
717
1,202
1,001
1,434
1,718
23
29
38
39
50
59 725
841
1,326
1,125
1,558
1,842
Note1: Input and output ratings are shown for sea level applications. The PRESTIGE Solo automatically derates the input at approxi-
mately 2% for every 1,000 feet of altitude. No alteration to the boiler or burner system is required.
Note 2: PRESTIGE Solo 399 output ratings are based off a thermal efficiency of 95.1%. Prestige Solo 250 output rating is based on
DOE heating capacity.
Note 3: The IBR rating is based on piping and pick up allowance of 1.15. This allowance should be sufficient for the standard
radiation requirements for a building load.
Note 4: Equivalent Direct Radiation (EDR) is based on 150 Btu/h per square foot EDR at 170ºF average supply temperature and total
net IBR rating.
Note 5: Minimum recommended system iron pipe size is based on temperature differential of 20ºF.
Note 6: Minimum recommended natural gas header size is based on using schedule 40 metallic pipe 0.30” w.c. pressure drop and
100 feet of total equivalent length at a gas inlet pressure of less than 2 psi. Consult National Fuel Gas Code for alternate sizing.
