29
System Piping
High Pressure Systems or Involving Fluid Separation
A heat exchanger is required between the Cascade and
the system piping as shown in Figure 33, page 35 when
operating under the following conditions:
- Standard 30 PSI Cascade - System operating
pressure greater than 30 PSI.
- High Pressure (HP) 80 PSI Cascade - System
operating pressure greater than 80 psi.
- Any Cascade requiring fluid separation (glycol
from water)
For applications involving multiple Cascade configu-
ration as shown in Figure: 33, page 35 in conjunction
with a system heat exchanger contact Triangle Tube
Technical Support for assistance in sizing heat
exchanger and piping recommendations.
NOTICE
