TriangleTube Prestige Cascade System - Manual (Page 49)

Replacement Parts
46
2
1
4
3
Fig. 36 : Cascade Kit Components for Solo 250 Boilers - Reverse Return with Valves - Return Piping
Item Part # Description
1 PSVLV13 1-1/4” NPT Union/Drain/Shut Off Valve Assembly
2
PSNIP11 1-1/4” NPT x 16” Pipe - RR with Valves
PSNIP10 1-1/4” NPT x 18” Pipe - RR
3 PSHOS02 1-1/2” NPT x 13” Flexible Hose/Union Assembly
4 PSELB09 1-1/2” NPT x 1-1/4” NPT 90º Reducing Elbow
Part # Description
PSLWC01 Low Water Cut Off with Probe - 3/4” NPT x 2” Long Insertion
PSFLG03 Flange ANSI to 3” NPSC
PSFLG02 Flange ANSI to Blind
PSGK24 Gasket ANSI
PSNUT03 5/16” - 18 Nut - Flanged
PSBLT03 5/16” - 18 x 3” Bolt - Flanged
PSCON07 Manual High Limit - 200ºF
PSWEL01 1/2” NPT x 1 1/2” Dry well for High Limit
PSCOM01 Heat Conductive Compound for High Limit
