3
3-20 Performing Setup from the Control Panel
IPX/SPX Setup options
For protocols other than IPX/SPX, the frame type is automatically enabled and does
not require setup, as follows:
To specify the frame types the ColorPASS uses for IPX/SPX protocols, choose
IPX/SPX Setup from the Protocol Setup menu. You must choose at least one frame
type to enable IPX/SPX protocols. The ColorPASS supports the following frame
types for IPX/SPX:
• For Ethernet—Ethernet 802.2, Ethernet 802.3, Ethernet II, and Ethernet SNAP
• For Token Ring—Token Ring and Token Ring SNAP
With this protocol: And these printing services:
This frame type is
automatically enabled:
AppleTalk PAP (Printer Access Protocol) Ethernet SNAP
TCP/IP with Ethernet LPD (Line Printer Daemon) Ethernet II
TCP/IP with Token Ring LPD (Line Printer Daemon) Token Ring SNAP
Exit Protocol Setup
AppleTalk Setup
TCP/IP Setup
IPX/SPX Setup
Protocol Setup
