LH 3000 OPERATING MANUAL
18 LH A GRO
CONSUMPTION FROM TANK
Two litre counters record the consumption from the tank. Both can be read from
this key.
TRIP LITRE CONSUMPTION FROM TANK:
Press and the trip consumption from the tank since last zero setting is
displayed.
TOTAL LITRE CONSUMPTION FROM TANK:
Keep the key pressed and the total consumption from the tank since last
zero setting will be displayed.
The litre consumption (trip and total) can be stored for later print of job cards. See
“JOBNO” and “MEMO”.
ZEROING OF COUNTERS:
TRIP COUNTER: Press . Press until “STO” is displayed followed by
3 quick warning tones. The counter is zeroed.
TOTAL COUNTER: Press simultaneously with for 3 seconds and
the counter is zeroed.
NOTE Zeroing or deleting of trip litre counter causes zeroing of TIME and TRIP
AREA at the same time.
WORKING PRESSURE
By pressing this key the working pressure of the sprayer is displayed in bars
(presupposed sensor is mounted).
WARNING: For pressure control the wanted pressure is encoded here as
follows:
1. Press for app. 3 seconds until the numerical keyboard is lit.
2. Encode wanted pressure.
3. Press again.
NOTE: The maximum deviation to be encoded during encode (“SYSTEM”-key)
point 07.
The warning function is only active when the implement works.
