Chapter 6. Library
0 : 150 BPS,
2 : 600 BPS
4 : 2400 BPS
6 : 9600 BPS
8 : 38400 BPS
10 : 115200 BPS
12 : 460800 BPS
1 : 300 BPS
3 : 1200 BPS:
5 : 4800 BPS
7 : 19200 BPS
9 : 57600 BPS
11 : 230400 BPS
13 : 921600 BPS
LCR X X P P S D D (8 bis binary)
P P : Parity Bits
0 0 : None, 0 1 : Odd, 1 0, 1 1: Even
S : Stop Bits
0 : 1 bits, 1 : 2 bits
D D : Data Bits
0 0 : 5 bits, 0 1 : 6 bits
1 0 : 7 bits, 1 1 : 8 bits
FlowControl Types of flow control
0: no flow control
1: RTS/CTS flow control
2: Xon/Xoff flow contorl
Returns None
Notice
SB_SetSerialInterface
Function Configures interface type of serial port.
Format Void SB_SetSerialInterface (int Interface);
Parameter Interface Interface ID of RS422/RS485
: RS422 (point to Point)
: RS422 (MultiDrop)
: RS485 (None_Echo)
4. : RS485 (Echo)
Returns None
Notice This function is needed only for serial model named “-C”, that is RS-
422/486 combo model; it is not needed when the user is developing
new hardware using Eddy-CPU.
DK board has two on-board serial ports. User can use the first serial
port for either RS422 or RS485 if the user sets DIP switch on DK board
to make it recognized as Eddy-DK.
SB_SendSerial
