Chapter 2. Getting Started
2.5.2 Eddy Flash Memory Map
Start address (size) Item Description
0x10000000 (4Kbyte) BootStrap Initialize hardware and calls bootloader
from flash memory to the RAM and
execute the bootloader.
0x10002000 (112Kbyte) Bootloader The Eddy boot loader is stored.
0x1001E000 (1.344Mbyte) Kernel Lemonix OS kernel is stored.
0x1012E000 (2.56MByte) Filesystem Various execution files are stored.
0x103AE000(64Kbyte)
0x103AE000(4.25Mbyte)
4MB: Configuration
8MB: Configuration
& User Memory
Information for system operating
environment is stored, and user can write
the user's data as remained size,
So user who use the 8M flash version can
used about 4MB flash memory.
2.5.3 Eddy directory structure
The Eddy file system consists of the following directories:
Name Description Access authority
/bin, /sbin,
/lib, /etc
Executables and system utilities Read & Write
/dev Device file Read & Write
/tmp
Tmp file system area of 15M bytes. The size of this
area is flexible; when application run by Eddy
requires more memory, this area can be reduced.
We recommend user to use this area for uploading
file through FTP.
Read & Write
/usr
Various program needed for the system and web
files
Read & Write
/flash
This is flash area which stores files that have to be
remained even if the power is reset, such as
environment setting. This area provides 64 KB
(4MB flash version) or 4.25MB(8MB flash
version)..
Read & Write
The Eddy’s entire folders are open for read & write. All loaded files are deleted after reboot except the data stored in
/flash.
