Slant Fin Corp. │ Installation and Operation Instructions CHS Series
6
2.0 SPECIFICATIONS
Table 2-1 CHS Specifications
DESCRIPTION CHS-85 CHS-110 CHS-155 CHS-175 CHS-200 CHS-250 CHS-300 CHS-399
CSA Input Modulation
1,4
[MBH]
17-85 21.6-108 31-155 31-175 31-200 31-250 79.8-299 79.8-399
DOE Heating Capacity
1,2
[MBH]
78 99 144 163 185 230 278 380
Net I=B=R Rating
1,2
[MBH]
68 86 125 141 160 199 239 330
DOE AFUE 2 [%] 95 95 95 95 95 95 94 95.4
Water Connections – NPT
[in.]
1 (Male) 1-1/4 (Male) 1-1/2 (Male)
Gas Connection - NPT, in. ½ (Male) ¾ (Male)
Vent/Air-inlet Pipe
Diameter
[in.] 3
2 or 3 3 4
Dimensions H x W x D [in.] 33-3/8 x 19-3/4 x 14-1/2 33-3/8 x 19-3/4 x 18-1/2 36-3/8 x 25-1/4 x 20
Approx. Boiler Weight
with Water [lbs]
110 180 250
Approx. Boiler Water
Content [Gallons]
3.2 4.9 6.4
Electrical Rating 120V/1Ph/60Hz/less than 12A
Notes:
1
Listed Input and Output ratings are at minimum vent lengths at an altitude of 0-2000ft. Numbers will be lower with
longer venting and/or altitudes greater then 2000ft.
2
Ratings based on standard test procedures prescribed by the U.S. Department of Energy; certified by AHRI. CHS-399
efficiency represents Thermal Efficiency (AFUE is not applicable).
3 The CHS requires a special venting system, use only vent materials and methods detailed in these instructions.
4
When operating with Propane models CHS-85 and CHS-110 have min/max Input Modulation rates of 17.6/88 and
22.6/113 MBH respectfully.
Wall mounting of unit requires two people to lift the boiler into place. Failure to follow
these instructions may result in property damage or personal injury.
High Altitude Operation
The CHS boiler is designed to operate at its maximum listed capacity in installations located at 0-2000ft above
Sea Level. Since the density of air decreases as elevation increases, maximum specified capacity should be de-
rated for elevations above 2000 ft [610 m] in accordance with Table 2-2.
Table 2-2 De-rate % for High Altitudes
Elevations 2001 ft [610 m] 3000 ft [914 m] 4000 ft [1219 m] 4500 ft [1372 m] 5000 ft [1524 m]
In Canada
1
de-rate by 10% de-rate by 10% de-rate by 10% de-rate by 10% de-rate % may vary
In USA 2 - de-rate by 4% de-rate by 8% de-rate by 8% de-rate by 12%
Notes:
1
Canada: Altitudes between 2000-4500 ft [610-1372 m], de-rate by 10%. Consult local authorities for de-rating
capacities for altitudes above 4500 ft [1372 m].
2 USA: De-rate capacity by 4% for every 1000 ft [305 m] over 2000 ft [610 m].
Combustion – At elevations above 2000 feet, the combustion of the boiler must be
checked with a calibrated combustion analyzer to ensure safe and reliable operation. It is
the Installers responsibility to check the combustion and to adjust the combustion in accordance with
Section 9.0. Failure to follow these instructions may result in property damage, serious injury, or death.
