SilentKnight IP Communicator - Manual (Page 18)

18 IP Communicator Series Installation Document — P/N 53109:I 4/26/2010
NOTE: When using a 411, AC Loss is reported from the FACP Trouble Relay output to the 411 Trouble Input.
The 411 does not have a 4th Input Channel. The 411 does allow any of the three Input Channels to be
programmed to report AC loss if desired.
RJ45
Ethernet/
Internet
Connection
Communicator
Fault to monitor
module on
FACP SLC
Loop
To Alarm,
Trouble,
Supervisory
Output Relays
on FACP
(2.2K Ω ELRs at
FACP)
Figure 18 Wiring IPDACT to 411/411UD and HP300ULX
H
P
3
0
0
U
LXt
o41
1U
D
2
.w
m
f
