IP Communicator Series
Product Installation Document
PN 53109:I 4/26/2010 10-xxx
1 IPDACT - Internet Protocol Digital Alarm Communicator/
Transmitter
The IPDACT, IPDACT-2 and IPDACT-2UD are compact, Internet Protocol Digital Alarm Communicators/Transmitters
designed to allow FACP status communication to a Central Station via the internet. Using Contact ID protocol from the
FACP, the IPDACT Series convert the standard DACT phone communication to a protocol that can be transmitted and
received via the internet. They also check connectivity between the FACP and Central Station.
The IPDACT Series operate in conjunction with the VisorALARM receiver, located at the Central Station. The Visor
ALARM receives signals transmitted by the IPDACT Series over the internet, instead of the traditional public switched
telephone lines, and sends the signals through a serial port to automation software for processing.
The installer must determine whether the FACP has enough reserve auxiliary power (24 VDC nonresettable, filtered, reg-
ulated) to supply the IPDACT Series module. The following table lists the power requirements for each version of the
IPDACT.
If the FACP cannot supply sufficient auxiliary power, the IPDACT Series module requires an auxiliary power supply such
as the HP300ULX as described in Section 2.3.
2 IPDACT Series Mounting/Wiring Options
There are several mounting options available for the IPDACT Series. The following sections describe these options. The
tables below are a guide for IPDACT Series mounting.
The following models are compatible with IPDACT Series Models.
IPDACT Model
Alarm Current
Standby Current
IPDACT
129 mA
100 mA
IPDACT-2
136 mA
93 mA
IPDACT-2UD
155 mA
98 mA
NOTES:
1. Following installation, refer to the Quick Startup Guide, supplied with the IPDACT, for programming and
activation of the IPDACT Series on the internet.
2. Although not required, the FACP Secondary Phone Line may be connected to the Public Switched
Telephone Network (i.e. a POTS line) for backup reporting.
3. Installation and wiring of this device must be done in accordance with NFPA 70, 72 and local ordinances.
4. The IPDACT can only be used for commercial fire applications.
Application (Power Source)
Mounting Location
Refer to Mounting Instruction Section
No Reserve Auxiliary Power
HP300ULX Enclosure
MS-9600(UD)LS
FACP Enclosure
MS-9200UD(E)
IPENC Enclosure
MS-9200UDLS(E)
FACP Enclosure
MS-9050UD
FACP Enclosure
MS-5UD-3(C)(E)
1
FACP Enclosure
FACP Enclosure
MS-25
2
HP300ULX Enclosure
Table 1 IPDACT Series Mounting/Wiring Options
