10 IP Communicator Series Installation Document — P/N 53109:I 4/26/2010
2.2 Mounting the IPDACT Series in the IPENC Enclosure
The IPDACT Series mounts to the factory-installed bracket inside the IPENC enclosure.
1. Secure IPDACT Series Module to the bracket using the four supplied screws as illustrated in Figure 9.
2. Wire the IPDACT Series as described in the following sections of this document.
3. Close the IPENC door and secure it to the enclosure with four supplied screws in locations indicated.
Figure 9 IPENC Installation
mounting
screws
door
screw
door screw
door
screws
IPENC Enclosure
IPDACT Module
