Section 1
Overview
1.1 5496 Description
The Model 5496 Intelligent Power Module provides additional power and notification circuits
to a Silent Knight addressable FACP. The 5496 can power all IntelliKnight compatible
notification appliances and auxiliary power modules.
The 5496 is capable of performing single or dual interlocking operations for pre-action and
deluge releasing systems. See Section 8.6 of FACP installation manual.
The 5496 has four output circuits that can be configured as notification or auxiliary power
circuits. Outputs are rated 3.0 A (6.0 A total for each 5496).
The 5496 is optically isolated, providing ground loop isolation and transient protection.
The 5496 provides configuration options that eliminate the need for sychronization modules
when using AMSECO, Faraday, Gentex, System Sensor, or Wheelock synchronization
appliances.
1.2 Agency Requirements
The 5496 has the same requirements as the main control panel. These requirements are listed
in Silent Knight addressable FACP Installation Manuals. Silent Knight Addressable FACP
Installation Manuals can be found on Silent Knight’s web site at www.silentknight.com.
1.3 About This Manual
This manual covers installation of 5496 hardware. Software configuration information is
contained in a Silent Knight addressable FACP Installation Manuals. Silent Knight
Addressable FACP Installation Manuals can be found on Silent Knight’s web site at
www.silentknight.com.
1.4 How to Contact Silent Knight
If you have a question or encounter a problem not covered in this manual, contact Silent
Knight Technical Support at 800-446-6444.
To order parts, contact Silent Knight Sales at 800-328-0103 or (203) 484-7161.
