Form P-UD, P/N 270285R4, Page 2
Rating Plate and Serial No.
Example of a Rating Plate, Model UDAP Example of a Rating Plate, Model UDBP
REZNOR ®
MERCER, PA. USA 16137
MADE IN MEXICO
UNIT HEATER NRTL
CATEGORY [ Z ]
ANSI Z83.8 [
A ] CSA 2.6 [ A’ ] UNIT HEATER
CSA .10.96 U.S. (2nd Ed.) UNIT HEATERS FOR RESIDENTIAL INSTALLATION
MODEL [ B ] [ C ]
SERIAL NO.
[ D ] VOLTS [ D ] PH [ D ] HZ MAXIMUM TOTAL INPUT [ D ] AMPS
TYPE OF GAS: [ E ]
FOR USE AT 0-2000 FEET, 0-610 METERS OF ALTITUDE.
ORIFICE SIZE [
F ] DRILL HAS BEEN FACTORY ADJUSTED
SEA LEVEL
NORMAL INPUT [ J ] BTU/HR
THERMAL OUTPUT CAPACITY [ L ] BTU/HR
MINIMUM INPUT(-2 MODELS) [ M ] BTU/HR
NORMAL MANIFOLD PRESSURE [ G ] IN.W.C.
MIN. PERMISSIBLE GAS SUPPLY PRESSURE
FOR PURPOSE OF INPUT ADJUSTMENT.
[ H ] IN.W.C.
CLEARANCES TO COMBUSTIBLE CONSTRUCTION: TOP- [ N ] “,
FLUE CONNECTION-6”, CONTROL SIDE-18”, OPP. SIDE- [ P ] “,
BOTTOM-1”, FRONT-36”.
FOR ALTERNATE INSTALLATIONS USE THE LATEST EDITIONS OF
THE APPROPRIATE STANDARD LISTED BELOW:
FOR AIRCRAFT HANGARS
USE STANDARD ANSI/NFPA 409
FOR PARKING STRUCTURES USE STANDARD ANSI/NFPA 88A
FOR REPAIR GARAGES USE STANDARD ANSI/NFPA 88B
THIS UNIT IS NOT FOR USE WITH DUCTS.
THIS UNIT IS NOT FOR USE WITH FILTERS.
IN THE EVENT THE FLAME ROLLOUT SENSOR CAUSES THE
HEATER TO SHUT OFF, DETERMINE AND CORRECT THE CAUSE.
FAILURE TO DO SO COULD RESULT IN PERSONAL INJURY OR
DEATH. TO RESET, DEPRESS THE BUTTON ON THE SENSOR
LOCATED ON THE BURNER BOX ASSEMBLY.
REZNOR ®
MERCER, PA. USA 16137
MADE IN MEXICO
NRTL
UNIT HEATER
CATEGORY [ Z ]
ANSI Z83.8 [ A ] CSA 2.6 [ A’ ] UNIT HEATER
MODEL [ B ] [ C ]
SERIAL NO. [ K ] HP
[ D ] VOLTS [ D ] PH [ D ] HZ MAXIMUM TOTAL INPUT [ D ] AMPS
TYPE OF GAS: [ E ]
FOR USE AT 0-2000 FEET, 0-610 METERS OF ALTITUDE.
ORIFICE SIZE [
F ] DRILL
SEA LEVEL
NORMAL INPUT [ J ] BTU/HR
THERMAL OUTPUT CAPACITY [ L ] BTU/HR
MINIMUM INPUT(-2 MODELS) [ M ] BTU/HR
NORMAL MANIFOLD PRESSURE [ G ] IN.W.C.
MIN. PERMISSIBLE GAS SUPPLY PRESSURE
FOR PURPOSE OF INPUT ADJUSTMENT.
[ H ] IN.W.C.
TEMPERATURE RISE RANGE FROM [ Q ] DEG. F. TO [ R ] DEG. F.
MAXIMUM EXTERNAL STATIC PRESSURE [ S ] IN. W.C.
CLEARANCES TO COMBUSTIBLE CONSTRUCTION: TOP- [ N ] “, FLUE
CONNECTION-6”, CONTROL SIDE-18”, OPP. SIDE- [ P ] “, BOTTOM-1”, FRONT-36”
FOR ALTERNATE INSTALLATIONS USE THE LATEST EDITIONS OF THE
APPROPRIATE STANDARD LISTED BELOW:
FOR AIRCRAFT HANGARS
USE STANDARD ANSI/NFPA 409
FOR PARKING STRUCTURES USE STANDARD ANSI/NFPA 88A
FOR REPAIR GARAGES USE STANDARD ANSI/NFPA 88B
INSTALLATION OF THIS UNIT IN AIRCRAFT HANGERS IN ACCORDANCE WITH
THE REQUIREMENTS OF THE ENFORCING AUTHORITIES AND IN PUBLIC
GARAGES IN ACCORDANCE WITH THE CAN/CGA-B149 (.1 OR .2 ) CODES.
THIS UNIT IS NOT FOR USE WITH FILTERS.
THIS UNIT MAY BE USED WITH DUCTS.
Rating Plate Key:
A Date of ANSI Standard K Blower Motor Horsepower
A’ Date of CSA Standard L BTU Thermal Output Sea Level
B Model No. M BTU Minimum Input Sea Level
C Month and Year of Manufacture N Top Clearance
D Voltage, Phase, 60 Hertz, Maximum Total Input Amps P Left Side Clearance
E Natural Gas or Propane Q Temperature Rise From (°F)
F Orifice Size R Temperature Rise To (°F)
G Manifold Pressure (3.5” w.c. Natural Gas; 10” w.c.
Propane)
S Maximum External Static Pressure (inches
w.c.)
H Minimum Gas supply Pressure (5.0” w.c. Natural Gas;
11.0” w.c. Propane)
Z Category
J BTU Normal Input Sea Level
