Form P-UD, P/N 270285R4, Page 12
Blower Backs and Blowers - UDBP and UDBS
Cabinet Parts (cont’d)
Belt Drive Blower
with Blower Back,
Code 73, on the
Cabinet - Sizes
150-400
Direct Drive Blower
with Blower Back
Adapter, Code 73,
on the Cabinet
- Sizes 100-125
Direct Drive
Blower attached
to the Cabinet
- Sizes 30-75
71
73
73
74
74
Code 29, Motor
(See page 8.)
Codes
78-88,
Motor
Mount
for
1-5HP
Motor
Code 26, Motor
Assembly (See
page 8.)
Code 26, Motor
Assembly (See
page 8.)
Blower Motor Mounting Components
Code Description 30 45 60 75 100 125 150 175 200 225 250 300 350 400
70 Restrictor Assembly 201408 - - - - - - - - - - - - -
70A Restrictor 194512 - - - - - - - - - - - - -
70B Restrictor Angle (3) 100892 - - - - - - - - - - - - -
70C Sheetmetal Screw (3) 195638 - - - - - - - - - - - - -
71 Blower Assembly 201401
See Code 74.
71A Blower 9 X 6 82111
71B Blower Mounting Angle (2) 201740
71C #10 x 1/2” Long Teks (6) 37661
72 Blower Back Corner Post - - - - 196239 201797 201798 201799
73 Blower Adapter Back Assy - - - - 201403 202931 201800 201801 201802
73A Adapter Back Bottom - - - - 202050 202050 201718 201719 201720
73B Adapter Back Top - - - - 196032 196032 201715 201716 201717
73C Adapter Back Left Side - - - - 197253 197253 201724 201725 201726
73D Adapter Back Right Side - - - - 197254 197254 201721 201722 201723
73E Screw - - - - (20) 195638 (34) 195638
(26)
195638
(34) 195638
73F Air Baffle Horizontal - - - - (2) 196344 202934 (2)202932 - - (2) 202933
73G Air Baffle Vertical - - - - 196345 196345 - - - - - - - -
73H Hanger Support Bracket Left - - - - - - 202759
73I Hanger Support Bracket Right - - - - - - 202760
73J
Bolt 1/4” X 5/8” (Hanger
Support Bracket to Adapter
Back)
- - - - - - (6) 47252
73K Nut 1/4” - 20 - - - - - - (6) 7328
74 Blower See CODE 71. 201770, 10x10 1360, 12x12
100658,
15x11
100659, 15x15
75A Key, 1/4” square x 1-1/4” long - - - - - - 16099
75B Blower Shaft - - - - - - 11303, 1 x 22 100747, 1 x 23
75C Blower Bearings - - - - - - 10437, SRC-16-1-1”
Motor Mounting 1/4 - 3/4 HP Motor 150-250 Motor Mounting 1-5 HP Motor 175-200 225-250 300-400
76 Motor Adjustment Bracket
Assembly
193996
78 Motor Mounting Plate for 1HP - 5HP 202839 202840 202841
79 Motor Mounting Plate Left Support 12576
76A Motor Adjustment Bracket 12575 80 Motor Mounting Plate Right Support 12577
76B 5/16-18 Spotweld Nut (2) 16233 81 Rod Bolt 5/16-18 (2) 12489
76C Hex Head Motor Adjust-
ment, Bolt, 5/16-18 x 4” lg
(2) 14668
82 Hex Nut 5/16-18 (2) 1035
83 Hex Nut 5/16-18 (Keps) (6) 6554
76D 5/16-18 Hex Nut (2) 1035 84 Flat Washer 5/16” (8) 1087
76E 1/4-20 x 3/4” long Hex Head,
Cap Screw
(2) 16246
85 5/16-18x3/4” lg Hex Head Cap Screw (6) 16247
86 5/16-18x1-1/2” lg Hex Head Cap Screw (2) 16248
76F 1/4-20 Hex Nut (Kep) (2) 10650 87 5/16”-18 Threaded Insert #ATS2-518 (4) 124260
76G 1/4” Flat Washer (4) 1320 88 #10-16 x 1/2” long Teks (4) 37661
77 Hardware Bag for CODE 76 64940
