Form P-UD, P/N 270285R4, Page 10
Drives - CODE 35 - Motor Pulley, CODE 36 - Blower Pulley, CODE 37 - Belt
UDBP and UDBS
OPEN MOTOR
Option AL
Voltage
Drive, Option AM
Motor Pulley Blower Pulley Average Belt Links
and Type* HP Option P/N Model Bore P/N Model Bore
150 and 175 1/4, 1/3 2, 3
AK1, AK2, AK3,
AK5, AK6, AK7
1, 2 4074 1VL34 1/2 111609 AK 99 1 “A-section” 3.8 ft
3, 4 13491 1VL40 1/2 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 13491 1VL40 1/2 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 13491 1VL40 1/2 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 13491 1VL40 1/2 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
1/2,
3/4, 1,
1-1/2
4, 5, 6, 7
AK1, AK2, AK3,
AK5, AK6, AK7
1, 2 13580 1VL34 5/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
1/2, 3/4 4, 5 AK8
1, 2 13580 1VL34 5/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
1, 1-1/2 6, 7 AK8
1, 2 110125 1VP34 7/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 106748 1VL40 7/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 106748 1VL40 7/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 106748 1VL40 7/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
2 8 AK1, AK2, AK3
1, 2 13580 1VL34 5/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
2 8
AK5, AK6, AK7,
AK8
1, 2 110125 1VP34 7/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 106748 1VL40 7/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 106748 1VL40 7/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 106748 1VL40 7/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, 400
3 9 AK2, AK3
9, 10, 11, 12 7962 1VL40 5/8 202652 AK124 1 “A-section” 3.8 ft
13, 14, 15, 16, 17,
18, 19
7962 1VL40 5/8 202653 AK94 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, 400
3, 5 9, 10
AK5, AK6, AK7,
AK8
9, 10, 11, 12 106748 1VL40 7/8 101414 BK130 1 “B-section” 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 202654 BK105 1 “B-section” 3.8 ft
UDBP and UDBS
TEFC MOTOR
Option AL
Voltage
Drive, Option AM
Motor Pulley Blower Pulley Average Belt Links
and Type* HP Option P/N Model Bore P/N Model Bore
150 and 175 1/4 19 AK1
1, 2 4074 1VL34 1/2 111609 AK 99 1 “A-section” 3.8 ft
3, 4 13491 1VL40 1/2 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 13491 1VL40 1/2 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 13491 1VL40 1/2 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 13491 1VL40 1/2 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
1/4 19
AK2, AK3, AK5,
AK6, AK7
1, 2 13580 1VL34 5/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 “A-section” 3.8 ft
150 and 175 1/3 20
AK1, AK2, AK3,
AK5, AK6, AK7
1, 2 4074 1VL34 1/2 111609 AK 99 1 “A-section” 3.8 ft
3, 4 13491 1VL40 1/2 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 13491 1VL40 1/2 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 13491 1VL40 1/2 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 13491 1VL40 1/2 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
1/2, 3/4, 1 21, 22,23
AK1, AK2, AK3,
AK5, AK6, AK7,
AK8
1, 2 13580 1VL34 5/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
1-1/2 24
AK1, AK2, AK3,
AK5, AK6, AK7
1, 2 13580 1VL34 5/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 7962 1VL40 5/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 7962 1VL40 5/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 7962 1VL40 5/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 7962 1VL40 5/8 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
1-1/2 24 AK8
1, 2 110125 1VP34 7/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 106748 1VL40 7/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 106748 1VL40 7/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 106748 1VL40 7/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, and 400
2 25
AK5, AK6, AK7,
AK8
1, 2 110125 1VP34 7/8 111609 AK 99 1 “A-section” 3.8 ft
3, 4 106748 1VL40 7/8 111609 AK 99 1 “A-section” 3.8 ft
5, 6, 7 106748 1VL40 7/8 19111 AK 84 1 “A-section” 3.8 ft
8, 9, 10, 11, 12 106748 1VL40 7/8 18797 AK 64 1 “A-section” 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 135200 AK 51 1 “A-section” 3.8 ft
150, 175, 200, 225, 250,
300, 350, 400
3 26
AK5, AK6, AK7,
AK8
9, 10, 11, 12 106748 1VL40 7/8 101414 BK130 1 “B-section” 3.8 ft
13, 14, 15, 16, 17 106748 1VL40 7/8 202654 BK105 1 “B-section” 3.8 ft
* Assume 17 belt links per foot. CODE 37, “A” Belt link, P/N 201809, Fenner #0408030; “B” Belt link, P/N 202655, Fenner #0408050.
