Rev-A-Shelf 4ASR Series User Manual
4asr series installation instructions, 10 min
2409 Plantside Drive
Jeffersontown, KY 40299
800.626.1126 • FAX: 502.491.2215
www.rev-a-shelf.com
I-4ASR-0411
4ASR Series
Installation Instructions
Hole Spread
CAUTION:
Be sure you are
screwing into
thick portion
of door.
4ASR-15 = 6-3/4”
4ASR-18 = 9-3/4”
4ASR-21 = 12-3/4”
Brackets are
adjustable up
to 5”
Inside of Cabinet Door
ESTIMATED ASSEMBLY
TIME:
10 MIN
CARE AND MAINTENANCE:
Clean with a damp cloth and
wipe parts dry.
2409 Plantside Drive
Jeffersontown, KY 40299
800.626.1126 • FAX: 502.491.2215
www.rev-a-shelf.com
I-4ASR-0411
4ASR Series
Installation Instructions
Hole Spread
CAUTION:
Be sure you are
screwing into
thick portion
of door.
4ASR-15 = 6-3/4”
4ASR-18 = 9-3/4”
4ASR-21 = 12-3/4”
Brackets are
adjustable up
to 5”
Inside of Cabinet Door
ESTIMATED ASSEMBLY
TIME:
10 MIN
CARE AND MAINTENANCE:
Clean with a damp cloth and
wipe parts dry.
