ESX-1320/ESX-1380 Local Management Guide 12-1
CHAPTER 12
THE MIB-2 STATISTICS SCREEN
Figure 12-1 shows the Interface Statistics screen. The Interface Statistics
screen displays error, collision, and traffic statistics for specified ESX
interfaces.
Figure 12-1 The Interface Statistics Screen
12.1 MIB-2 STATISTICS SCREEN FIELDS
The following list describes the Interface Statistics screen fields:
In Octets
This field displays the number of octets (bytes) received by the interface.
In Unicast Pkts
This field displays the number of unicast packets (packets destined for
one specific address) received on the interface.
090832
IN OCTETS:
IN UNICAST PKTS:
IN NONUCAST PKTS:
IN DISCARDS:
IN ERRORS:
INTERFACE: 1 INTERFACE: 2 INTERFACE: 3
RETURN INTFACE 1 INTFACE 2 INTFACE 3 UPDATE-FREQ 3 Sec
CLEAR COUNTERS
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
INTERFACE STATISTICS
OUT OCTETS:
OUT UNICAST PKTS:
OUT NONUCAST PKTS:
OUT DISCARDS:
OUT ERRORS:
