The Main Menu Screen
ESX-1320/ESX-1380 Local Management Guide 3-5
3.3 THE MAIN MENU SCREEN
The Main Menu screen is the starting point from which all the Local
Management screens are accessed. Figure 3-3 shows the Main Menu
screen.
Figure 3-3 The Main Menu
The Main Menu screen displays the following menu items:
• Setup Menu – The Setup Menu provides access to Local Management
screens that are used to configure the ESX.
• Status Menu – The Status Menu provides access to the Component
Status screen which displays the operational and administrative status
of ESX MIB components.
• Statistics Menu – The Statistics Menu provides bridge statistics and
performance information for the switch interfaces of the ESX.
• MIB Navigator – The MIB Navigator is a Local Management utility
which allows the user to access, monitor, and set specific Management
Information Base (MIB) items within the ESX.
Flash Image Version: XX.XX.XX
MAIN MENU
090821
SETUP MENU
STATUS MENU
STATISTICS MENU
MIB NAVIGATOR
ESX-13XX Local Management
EXIT
Event Message Line
