ESX-1320/ESX-1380 Local Management Guide 7-1
CHAPTER 7
THE FLASH DOWNLOAD SCREEN
This chapter explains how to use the FLASH Download screen to
download a firmware image from a TFTP server to the ESX. Figure 7-1
shows the FLASH Download screen.
Figure 7-1 The FLASH Download Screen
NOTE
FLASH download operations require a properly named
download file and a properly configured download server.
FLASH DOWNLOAD
Download Method:
Reboot After Download:
Last Image File Name:
Last Image Server IP:
Download Server IP:
Download File Name:
[RUNTIME]
[YES]
0.0.0.0
c:\tftpboot\f2_proxy.hex
0.0.0.0
c:\tftpboot\f2_proxy.hex
EXECUTE RETURN
090834
TFTP Gateway Server IP: 0.0.0.0
Event Message Line
ESX-13XX Local Management Flash Image Version: XX.XX.XX
This section appears only if BOOTPROM is selected as Download Method.
