MBOX
®
MINI USER MANUAL
135
*
Special commands require that the parameter value be held
for three seconds, followed by an immediate change to
value 0 (without any other values in between).
**
Special command that requires the value to be held for
250mS, followed by an immediate change to 0 (with no val-
ues in between)
Master
Chan
Size
Function
Default
Snap
1
1
Pixel Map Level
255
N
2
1
Control Selector
0
Y
3
1
Texture Effect 1
0
Y
4
1
Modifier 1a
0
N
5
1
Modifier 1b
0
N
6
1
Red
255
N
7
1
Green
255
N
8
1
Blue
255
N
9
1
Intensity
255
N
10
1
0
Y
11
1
Master Audio Volume
255
N
Master Control Channel
Values
Command
0
None/Idle
10-19
Version HUD
20-29
Performance HUD
40-49
Master/Keystone/Shutter HUD
50-59
Layer HUD 1
70-71
Raw Art-Net HUD
80-84
Show pix-map context view
85-89
Show pix-map fixture view
110-111
Timecode HUD Center
112-113
Timecode HUD Top Right
114-115
Timecode HUD Top Left
116-117
Timecode HUD Bottom Right
118-119
Timecode HUD Bottom Left
120
Show Alignment Rectangles No Group,
No X or O
121
Show Alignment Rectangles Group 1, No X or O
122
Show Alignment Rectangles Group 2, No X or O
123
Show Alignment Rectangles Group 3, No X or O
124
Show Alignment Rectangles Group 4, No X or O
125
Show Alignment Rectangles Group 5, No X or O
126
Show Alignment Rectangles Group 6, No X or O
127
Show Alignment Rectangles Group 7, No X or O
128
Show Alignment Rectangles Group 8, No X or O
129
Show Alignment Rectangles Group 9, No X or O
130
Show Alignment Rectangles Group, No X and O
131
Show Alignment Rectangles Group 1, X and O
132
Show Alignment Rectangles Group 2, X and O
133
Show Alignment Rectangles Group 3, X and O
134
Show Alignment Rectangles Group 4, X and O
135
Show Alignment Rectangles Group 5, X and O
136
Show Alignment Rectangles Group 6, X and O
137
Show Alignment Rectangles Group 7, X and O
138
Show Alignment Rectangles Group 8, X and O
139
Show Alignment Rectangles Group 9, X and O
201
Run script (script selected by index value set on
Master Control Selector parameter) **
202
Switch to Pixel Mapping file (file selected by
index value set on Master Control Selector
parameter) **
203
Switch to Alignment Rectangle file (file selected
by index value set on Master Control Selector
parameter) **
220
Cancel keyboard HUD
230
File Sharing On
231
File Sharing Off
232
ARD On
233
ARD Off
234
Become Backup (turn on Backup mode pref)
235
Become Primary (turn off Backup mode pref)
240
Rescan Media Library *
244
Enable Pixel Mapping Output *
245
Disable Pixel Mapping Output *
246
Enable Masked Pixel Mapping fixtures *
247
Disable Masked Pixel Mapping fixtures *
250
Quit Mbox Application *
251
Shutdown Computer *
252
Restart Computer *
253
Restart Mbox Application *
