78 BEST BOY 4000 ® SPOT LUMINAIRE USER MANUAL
Step 5. Noting proper orientation of carrier, insert new designer color filter into position and push until carrier clicks
into place. Refer to Figure 4-13 for wheel positions.
Step 6. Replace Head Cover.
Figure 4-13: Designer Color Wheel Positions
2
3
4
1
OPEN
7
6
5
