PRG Best Boy 4000 User Manual User Manual
Page 50
42
BEST BOY 4000
®
SPOT LUMINAIRE USER MANUAL
Medium Random
103-106
Fast Random
107-109
Speed
110-255
Slow
110
Fast
255
30
MACRO
Macro Control
home: 0
None
0
Macro control overrides the
DMX control for that
parameter.
Iris - square wave
1
Iris - sine wave
2
Iris - sawtooth
3
Iris - reverse sawtooth
4
Iris close
5
Iris open
6
Zoom/Iris close
7
Zoom/Iris open
8
Framing - square wave
9
Framing - sine wave
10
Framing - sawtooth
11
Framing - reverse sawtooth
12
Framing close
13
Framing open
14
Zoom/Framing close
15
Zoom/Framing open
16
Iris/Framing alternate square wave
17
Iris/Framing alternate sine wave
18
Frost - sine wave
19
Frost - sawtooth
20
Frost - reverse sawtooth
21
Edge - sine wave
22
Edge - sawtooth
23
Edge - reverse sawtooth
24
Fire 25
Water 26
Clouds 27
31
MACRO SPEED
Macro Speed control
home: 0
Speed Range
0-246
Slow
0
Fast
246
Random Speed - Slow Rate
247-249
Random Speed - Medium Rate
250-252
Random Speed - Fast Rate
253-255
32
FOCUS TIME
Refer to
home: 255
33
COLOR TIME
home: 255
34
IMAGE TIME
home: 255
35
BEAM TIME
home: 255
Table 3-1: Best Boy DMX Channel Mapping (Continued)
Channel
Function
Description
8-Bit
16-Bit
