54 BEST BOY 4000 ® SPOT LUMINAIRE USER MANUAL
Mechanism Errors
Errors will be shown after the mechanism code, for example: PAN:Comm Error.
Other Errors
Error Code Explanation Solution
Cal Error
Error resetting position values in motion
processor at beginning of calibration Check CAN cables/connections, motor
control board
Cal Timeout
An action during calibration took longer
than expected Check CAN cables/connections, motor
control board
Comm Error
Error communicating with motion
processor Check CAN cables/connections, motor
control board
Get Position Error
Error when retrieving current position
from motion processor Check CAN cables/connections, motor
control board
Init Error
Error during initialization of motion
processor Check CAN cables/connections, motor
control board
Motion Error
Mechanism's actual position is too far
from its commanded position
Check mechanism motion
No Sensor
During calibration, no sensor was found
in the range of travel Check for mechanism motion, sensor
operation
No Stop
Mechanism which calibrates to a
physical stop did not find that stop
Check mechanism
Sensor Stuck
During calibration, could not find either
edge of the sensor or the sensor did not
turn off as expected
Check for mechanism motion, sensor
operation
Spin Error
Error while sending spin command to
motion processor Check CAN cables/connections, motor
control board
Stop Spin Error
Error while sending stop spin command
to motion processor Check CAN cables/connections, motor
control board
Error Code Explanation Solution
Ballast Errors: Parity, Overrun,
Bad Header, Msg Too Long
Various ballast errors Check ballast comm cable/connections
Ballast Heat Sink Over Temp Ballast too hot Check fans
Ballast Short Detected Short circuit on ballast output Check wiring
Ballast Timeout: Lamp Strike Lamp failed to strike Check igniter, lamp
CAN Comm Error
Stopped receiving CAN messages from
motion processor Check CAN cables/connections, motor
control board
Crossload Timeout
Crossload execution took too long due to
error
Remove any incoming DMX, retry
Data not crossload format
Data in memory is not proper format for
crossload
Load software via computer
DMX busy: cancel crossload
Cannot execute crossload with traffic on
DMX line Remove incoming DMX control for cross
load
DMX: UART transmit error Transmit buffer busy when trying to send Remove any incoming DMX, retry
Fuse Blown One or more fuses are blown Check fuse on specified board
