Left - right Travel ± 11.5” (29 cm.)
8
DIReCTIOnS fOR USe
MAnUAl lOnGITUDInAl TRAvel OPeRATIOn
CAUTIOn When operating the table’s locking knob be sure to avoid pinching. Keep your fingers and
other materials clear from the pinch point. Both locking knobs must be securely tightened at
all times - Travel can occur if the locking knobs are not secured by inadvertently pushing on
the end of the table or by tilting the table.
The table is designed to allow travel in either the left or the right direction as shown. This feature
should only be used when the table is level.
lOCKInG KnOb OPeRATIOn
A Locking Knob is provided on each side of the table just
under the side rail.
Rotate the locking knob several turns counter-clockwise
to loosen. Slide the table in the desired direction. Rotate
the locking knob clockwise until tight to secure the table
against traveling.
PATIenT ReSTRAInT STRAP
The Patient Restraint Strap must be used during all procedures to prevent the patient from
falling off the table.
CAUTIOn
The strap has Velcro® attached to the ends. The Strap is attached as follows:
1. Place the center of the strap around the patient’s waist.
Relocate the strap as necessary for adequate clearance.
2. Take the ends of the strap down around the tabletop.
Pull the strap snug underneath the table and press the two
Velcro® ends together.
3. Check the strap to assure adequate patient restraint prior
to using the Trendelenburg functions.
