WARNINGS /
SYMBOLS
14
DIRECTIONS FOR USE
MOVING THE TABLE
Before doing any work on the
table, disconnect the power
cord from the power outlet
and secure the electrical
cord, and foot controls for
moving.
The table weighs as much
as 200 lbs.
DO NOT lift or
move the unit without using
proper safety procedures
or equipment.
DO NOT turn
the table on its side for any
reason. To do so could
cause damage to the base
and
will void the warranty.
There are no serviceable
items that require this action
.
Never lift the table by grasping
the table top as the table
top is not
designed to hold
the weight of the base and
you could damage the table.
at low height range
Grasp
at base
corner
The table weighs approximately 200 lbs. You will need 4 people working
together to move the table. Never lift the table by grasping the table top
as the table top is not designed to hold the weight of the base and you
could damage the table and the electronics that operate the tabletop.
If you need to move the table, place one person at each corner of the
table. Have each person firmly grasp the metal leg at the bottom and lift
the table from the base. As when moving any piece of heavy equipment,
bend at the knee and lift with your legs beneath you and not with your
back. Be aware and use proper, safe procedures for moving a table of
this size to prevent injury to yourself or the table. We strongly recommend
that a flatbed dolly be used that can hold the entire table if moving the
table involves a longer distance.
IF THE TABLE WILL NOT CHANGE HEIGHT OR POSITION
(ELECTRIC/HYDRAULIC MODEL):
IF THE TABLE IS MAKING NOISE DURING HEIGHT ADJUSTMENT:
DIRECTIONS
FOR
USE
CAUTION
CAUTION
• Check that the keyswitch on the shelf is in the “on” position.
• Check the outlet to be sure that it has power and that the power cable is plugged
in. Try each Foot Control and Hand Control to see if any work. If any work, then
possibly there is a loose connection or a faulty controller.
• Unplug the power cable from the wall outlet.
• Make sure that all male and female connectors are firmly pushed into each other.
Even a slight misconnection can cause a possible malfunction.
• Plug the unit back into the wall and check the controls again. If one or more of
the controls still do not work, contact Customer Service at 800-558-8850.
• If you hear squealing or a pop during the height adjustment, this may be related
to lack of lubrication in the hydraulic cylinders. We recommend that you imme-
diately cycle the table fully up/down at least seven times. If this does not work,
then let the motor cool down for at least two hours and repeat the procedure.
The table should return to its normal quiet mode. Refer to “DIRECTIONS FOR
USE; Daily Cycling.”
TROUBLESHOOTING
