NAV440 User Manual
7430‐0131‐01 Rev. F
Page 71
Test 0 (Detailed BIT and Status) Packet
Table 37 Test 0 Packet
Test (‘T0’ = 0x5430)
Preamble Packet Type Length Payload Termination
03.3x5555 0x5430 0x1C
T
T
his packet contains detailed BIT and status information. Full BIT Status details is described in Chapter 11. Built In
est (BIT).
Table 38 T0 Payload
T0 Payload Contents
Byte
ffset O
Name Format Scaling Units Description
0 BITstatus U2 — — Master BIT and Statu
Field
s
2 hardwareBIT U2 — — Hardware BIT Field
4 hardwarePowerBIT U2 — — Hardware Power BIT Field
6 hardwareEnvironmentalBIT U2 — — Hardware Environmental
BIT Field
8 comBIT U2 — — communication BIT Field
10 comSerialABIT U2 — — Communication Serial A
BIT Field
12 comSerialBBIT U2 — — Communication Ser
BIT Field ial B
14 softwareBIT U2 — — Software BIT Field
16 softwareAlgorithmBIT U2 — — Software Algorithm BIT
Field
18 softwareDataBIT U2 — — Software Data BIT Field
20 hardwareStatus U2 — — Hardware Status Field
22 comStatus U2 — — Communication Statu
Field s
24 softwareStatus U2 — — Software Status Field
26 sensorStatus U2 — — Sensor Status Field
Output Packets (Polled or Continuous)
Scaled Sensor Data Packet 0
Table 39 Scaled Sensor Data Packet 0
Scaled Sensor Data (‘S0’ = 0x5330)
