Mounting the Printer
• Remove the two thumb-screws from
the bracket attached to the top of the
drive bays.
• Loosen the three screws in the
bracket attached to the printer
• Gently place the printer on top of the
drive bays.
• Line up the holes from which you
removed the screws in the lower drive
bay bracket with the key-ways of the
bracket attached to the printer and
replace screws loosely threaded.
