UG_1x66B_015 73M1866B/73M1966B Reference Driver User Guide
Rev. 2.7 91
7.14.5 M1966_IET_t
Description
This Interval and Event Table structure (IET) is internally used by the driver to store threshold parameters
for monitoring line current and voltage. Each measuring entity (current and voltage) has its own separate
IET table of up to 10 entries, or rows with the following attributes: the IET row number, lower and upper
bound thresholds, and an event identifier that will be sent in M1966_LINE_STATE event to the application
when this IET entry is entered.
The IET table is managed by the application layer via a group of line measurement IOCTLs.
Management of IET table entry consists of runtime update of IET table, and the start and stop
measurement processing which access these IET tables.
Prototype
typedef struct
{
unsigned int row;
unsigned int inverval_min;
unsigned int interval_max;
unsigned int event;
}
M1966_IET_t;
Parameters
Data Type Name Description
unsigned int row IET table index (0 to 9).
unsigned int interval_min Lower bound range (in milliamps for current, or millivolts for
voltage).
unsigned int interval_max Upper bound range (in milliamps for current, or millivolts for
voltage).
unsigned int event Event identifier sent to application layer.
