6.3 FXO Hook Switch Control Services

The configuration and control of the FXO Hook Switch is accomplished by using the IOCTLs summarized
in Table 3.

Table 3: FXO Hook Switch Control Services

Events and Status

Description

Descriptor

M1966B_ENNOM_DELAY_TIMER

Allows the developer to tune the EnNom response
timer.

Channel

M1966_ATH1

Issue off-hook in the FXO interface.

Channel

M1966_ATH0

Issue on-hook in the FXO interface.

Channel

M1966_ATDP

Pulse dial.

Channel

M1966_ATDP_CANCEL

Pulse dial abort or cancel.

Channel

M1966_ATDP_PARAM

Pulse dial parameters.

Channel

M1966_FLSH_CFG

Configure of flash-hook parameter for the FXO
interface.

Channel

M1966_FLSH_SET

Perform hook flashing on the FXO interface.

Channel

M1966_SEND_WETTING_PULSE Perform a wetting pulse on the FXO interface.

Channel

6.3.1 M1966_ENNOM_DELAY_TIMER

This IOCTL allows an application program to change the ENNOM delay timer from the default value of
350 ms to any value within the valid ranges of 10 to 350 ms, inclusive

Description

Delaying of ENNOM bit setting is required for loop stabilization during off hook operation. However, the
duration depends largely on the quality of the hook circuit design. The driver uses the default setting of
350 ms an optimized choice for response time and voice quality. This IOCTL allows developers to tune
this timing value to suit their specific needs.

#define M1966_ENNOM_DELAY_TIMER _IOWR(0xA4, 0xF8, unsigned int)

Prototype

int ioctl (

int chan_fd,

int M1966_ENNOM_DELAY_TIMER,

unsigned long param );


Parameters

Data Type

Name

Description

int

chan_fd

Channel descriptor.

int

M1966_ENNOM_DELAY_TIMER

I/O control identifier for this operation.

unsigned long

param

The desired ENNOM delay duration.
Range from 10 to 350 ms, inclusive.


Return Values

Data Type

Description

int

Always returns 0.
