7.12.7 M1966_GPIO_INTR_POLARITY
Description
GPIO Interrupt signal transition edge selection. The defines the interrupt source as being either on a
rising or a falling edge of the corresponding GPIO pin. If configured as M1966_GPIO_POL_RISING a
rising edge will trigger an interrupt from the corresponding GPIO pin. If configured as
M1966_GPIO_POL_FALLING
a falling edge will trigger an interrupt from the corresponding GPIO pin.
Prototype
typedef enum {
M1966_GPIO_POL_RISING = 0, /* Sig transition edge polarity - RISING */
M1966_GPIO_POL_FALLING = 1 /* Sig transition edge polarity - FALLING */
}
M1966_GPIO_INTR_POLARITY;
Parameters
Name
Value
Description
M1966_GPIO_POL_RISING
0
Interrupt edge selection – RISING.
M1966_GPIO_POL_FALLING
1
Interrupt edge selection – FALLING.
7.12.8 M1966_GPIO_CONFIG_t
Description
This structure is used by the M1966_GPIO_CONFIG IOCTLs to read or write GPIO configuration. The
first field in the config structure is the command action field – GET or SET. For the GET command the
“direction” and “polarity” fields are returned if successful.
Prototype
typedef struct gpio_config
{
M1966_GPIO_CONFIG_COMMAND command; /* command */
M1966_GPIO_NUMBER gpio; /* GPIO number */
M1966_GPIO_SIGNAL_DIR direction; /* signal direction */
M1966_GPIO_INTR_POLARITY polarity; /* intr edge selection */
}
M1966_GPIO_CONFIG_t;
Parameters
Data Type
Name
Description
M1966_GPIO_CONFIG_COMMAND command
GET or SET GPIO config command.
M1966_GPIO_NUMBER
gpio
GPIO number.
M1966_GPIO_DIRECTION
direction
GPIO pin direction – input/output.
M1966_GPIO_INTR_POLARITY
polarity
Interrupt on signal transition edge polarity.
