X3 0, 2 – 4,
14 0, 2 – 4, 14 plus
extended result
codes 0, 2 – 4, 14 0 – 1, 3 – 5, 7,
9 - 14, 22, 23 0–1, 3–5, 7, 9–14,
22, 23 plus
extended result
codes 0–1, 3–5, 7,
9-4, 22, 23
X4 0, 2, 4,
6, 14 0, 2, 4, 6, 14
plus extended
result codes 0, 2, 4, 6, 14 0 – 1, 3 – 5, 7,
9 - 14, 22, 23 0–1, 3–5, 7, 9–14,
22, 23 plus
extended result
codes 0–1, 3–5, 7,
9–14, 22, 23
Pre Dial Post Dial
X5 0, 2 –
4, 7, 14 0, 2 – 4, 7, 14
plus extended
result codes 0, 2 – 4, 7, 14 0 – 1, 3 – 5, 9
- 14, 22, 23
0–1, 3–5, 9–14,
22, 23 plus
extended result
codes 0–1, 3–5, 9-
14, 22, 23
X6 0, 2, 4,
6 - 7,
14 0, 2, 4, 6 - 7, 14
plus extended
result codes 0, 2, 4, 6 - 7,
14 0 – 1, 3 – 5, 9
- 14, 22, 23 0–1, 3–5, 9–14,
22, 23 plus
extended result
codes 0–1, 3–5, 9-
14, 22, 23
X7 0, 2 –
4, 7, 14 0, 2 – 4, 7, 14
plus extended
result codes 0, 2 – 4, 7, 14 0 – 1, 3 – 5, 7,
9 - 14, 22, 23
0–1, 3–5, 7, 9–14,
22, 23 plus
extended result
codes 0–1, 3–5, 7,
9-14, 22, 23
X8 0, 2, 4,
6 - 7,
14 0, 2, 4, 6 - 7, 14
plus extended
result codes 0, 2, 4, 6 - 7,
14 0 – 1, 3 – 5, 7,
9 - 14, 22, 23 0–1, 3–5, 7, 9–14,
22, 23 plus
extended result
codes 0–1, 3–5, 7,
9-14, 22, 23
2.23 X[n] – Select Result Code Set
n = 0 to 8 (factory default = 4)
The X[n] command selects normal or extended result code reporting and enables or disables advanced
functions.
X0
Enable Result Codes 0-4, 14.
X1
Enable Result Codes 0-5, 10-14.
X2
Enable Result Codes 0-6, 10-14.
X3
Enable Result Codes 0-5, 7, 10-14.
X4
Enable Result Codes 0-7, 10-14 (default).
X5
Enable Result Codes 0-5, 10-14 and detect BUSY at OFF HOOK.
X6
Enable Result Codes 0-6, 10-14 and detect BUSY at OFF HOOK.
X7
Enable Result Codes 0-5, 7, 10-14 and detect BUSY at OFF HOOK.
X8
Enable Result Codes 0-7, 10-14 and detect BUSY at OFF HOOK.
Result Code 0 = OK
Result Code 1 = CONNECT
Result Code 2 = RING
Result Code 3 = NO CARRIER
Result Code 4 = ERROR
