73M2901CE AT Command User Guide

Rev. 2.0

13

2. Mode V.22bis, Protocol enabled (through S25), Normal result codes.

V.22bis

Connection

V.42

Detection

Connect

Result

Data

Mode

DCD

DSR



3. Mode V.22bis, Protocol enabled (through S25), No result codes.

V.22bis

Connection

V.42

Detection

Data

Mode

DCD

DSR

4. Mode V.22bis, No Protocol, Extended result codes

V.22bis

Connection

Carrier

Result

Protocol/Connect

Result

Data

Mode

DCD

DSR


5. Mode V.22bis, No Protocol, No result codes.

V.22bis

Connection

Data

Mode

DCD

DSR
