UG_12xxF_016

73S12xxF Software User Guide

Rev. 1.50

47

#define BPS9600

9600L // 0x00002580 (9600 +- 1%)

#define BPS14400

14400L

#define BPS19200

19200L

#define BPS28800

28800L

#define BPS38400

38400L

#define BPS57600

57600L

#define BPS57688

57688L

#define BPS115200

115200L // 0x0001C200 (115200 +- 1%)

#define BPS116129

116129L // 0x0001C200

#define BPS225000

225000L

#define BPS230400

230400L


// Defines for Mechanical.
#define ACCEPT

0x00000001L

#define EJECT

0x00000002L

#define CAPTURE

0x00000004L

#define LOCK

0x00000008L


// Defines for Features.
#define ATR_CONFIGURATION 0x00000002L
#define INSERT_ACTIVATION

0x00000004L

#define VOLTAGE_SELECTION 0x00000008L
#define CLOCK_FREQ_CHANGE

0x00000010L

#define BIT_RATE_CHANGE

0x00000020L

#define AUTO_NEGOTIATION

0x00000040L

#define AUTO_PPS

0x00000080L

#define CLOCK_STOP

0x00000100L

#define NAD_NOT_NULL

0x00000200L

#define AUTO_IFSD

0x00000400L

#define TPDU

0x00010000L

#define SHORT_APDU

0x00020000L

#define EXTENDED_APDU

0x00040000L


// Defines for LcdLayout
#define NO_LCD

0x0000

#define LCD_ROWS

0xFF00

#define LCD_COLS

0x00FF


// Defines for PinSupport.
#define NO_PIN

0x00

#define VERIFY

0x01

#define MODIFY

0x02


struct USB_CCID_t
{
unsigned char Length;

// Always 54 (0x36).

unsigned char DescriptorType;

// Always CCID_DESCRIPTOR = 0x21

unsigned int

CCID;

// 0x0100 CCID version number.

unsigned char MaxSlotIndex;

// Application specific.

unsigned char VoltageSupport;

// Application specific.

unsigned long Protocols;

// Application specific.

unsigned long DefaultClock;

// 3600kHz (0x00000E10).

unsigned long MaximumClock;

// 7200kHz (0x00001C20)

unsigned char NumClockSupported; // 3. (1800, 3600 and 7200 kHz).
unsigned long DataRate;

// 9600 bps (0x00002580).

unsigned long MaxDataRate;

// 115200 bps (0x0001C200).
