2-6 Setup and Configuration
Writer: Caroline Juszczak Project: Compaq Integrated Remote Console User Guide Comments: 281862-00x
File Name: C-CH02.DOC Last Saved On: 11/20/98 12:54 PM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Configuring Integrated Remote
Console
Use the System Configuration Utility to configure IRC. Table 2-1 summarizes
the System Configuration Utility configuration options and their default values.
Table 2-1
Integrated Remote Console Configuration Summary
Parameter Configuration Value
(default settings in bold)
General Integrated Remote Console Information
Remote Console Functions Enabled/Disabled
Communication Device External Modem/Internal Modem/Direct Connect
Keyboard United States, Belgian, British, Danish, Finnish,
French, French Canadian, German, Italian,
Japanese, Latin American, Norwegian, Portuguese,
Spanish, Swedish, Swiss French, Swiss German
Communication Settings
COM Port COM1, COM2, COM3, COM4
Interrupt (Internal Modem only) IRQ3, IRQ4, IRQ5
Sharing Options Shared, Dedicated
Maximum DTE Baud Rate 19200, 38400, 57600, 115200
Data Bits 7, 8
Parity None, Even, Odd
Stop Bits 1,2
Continued
