A-3
Compaq Integrated Remote Console User Guide
Writer: Caroline Juszczak Project: Compaq Integrated Remote Console User Guide Comments: 281862-002
File Name: J-APPA.DOC Last Saved On: 11/20/98 10:23 AM
COMPAQ CONFIDENTIAL - NEED TO KNOW REQUIRED
Suggested Settings When Modem is
Shared in Windows NT 4.0
The following table contains the suggested configuration settings for Integrated
Remote Console when the modem usage is set to shared. These settings are
dependent upon how the operating system is configured and assume that the
modem was installed with the default settings. It is also assumes that the correct
INF file is used when the modem is installed under Windows NT. Modems
which require an INF file other than the set shipped standard with the operating
system are noted.
NOTE: The Port Setting for all modems is 8-N-1.
Table A-2
Shared in Windows NT 4.0 Environment Modem Settings
Modem Selected Baud Init String #1 Init String #2
Cardinal Connecta 56K
External Fax Modem 1
115200 AT&F1E0Q0V1&C1&D2 ATS7=60S19=0M1&M4&K1&H1&R2&I0B0X4
Compaq SpeedPaq 144 Data
Fax Modem
19200 AT&FE0V1&C1&D2W1X4S95=47 ATS7=60S30=0L0M1\N3%C1S101=35\Q3B0
N1X4
Compaq Microcom 415
External Fax Modem 1
57600 AT&FE0Q0V1&C1&D2S95=47 ATS7=60S30=0L0M1\N3%C3&K3B0N1X4
Compaq Microcom 510 56K
Ext Fax Modem 1
57600 AT&FE0%U2V0&D2&C1 ATS7=60\T0L1M1\N3%C3\Q3B0X4
Compaq Netelligent 56K ISA
Fax Modem 1
57600 AT&FE0V1&C1&D2S95=47 ATS7=60S30=0L1M1\N3%C3&K3B+MS=,1,,,,
X4
Diamond SupraExpress 56e 1 115200 AT&F2E0&C1&D2V1Q0W2 ATS7=60S30=0LM1&Q5\N3%C3&K3BN1X4
Hayes Accura 144 Data Fax
Modem
11900 AT&FE0V0W1&C1&D2S95=47 ATS7=60S30=0L0M1&Q5S36=7S48=7S46=1
38&K3
Continued
1 Requires INF file from modem manufacturer to complete modem installation in Windows NT. (Appropriate
INF file not shipped with Windows NT.)
