5-7
Cisco Unified Communications Manager Configuration Guide for the Cisco TelePresence System
OL-21851-01
Chapter 5 Configuring and Managing the Cisco Unified IP Phone
Configuring the Cisco Unified IP Phone
Protocol Specific Information
Link the Cisco TelePresence device to Cisco Unified Communications Manager phone profiles for the
presence group and security-related SIP phone settings using the information in
Table 5-2 as a guide.
Note The “Required” column in the table reflects fields marked with an asterisk ( * ) in the administration
interface, which are required entries for basic configuration.
Certification Authority Proxy Function (CAPF) Information
Table 5-3 describes fields found in the Certification Authority Proxy Function (CAPF) Information
section on the Phone Configuration page. Leave all fields unchanged.
Table 5-2 Cisco Unified IP Phone 7970 Series Protocol-Specific Information
Field Required? Setting
Packet Capture Mode Yes
Packet Capture Duration — 0
Presence Group Yes Standard Presence group.
SIP Dial Rules —
MTP Preferred Originating Codec Yes 711ulaw
Device Security Profile Yes Use the default setting.
Note For more information about configuring
Cisco Unified CM security features, refer
to the
Cisco Unified Communications
Manager Security Guide, Release 7.1(2) .
Rerouting Calling Search Space —
SUBSCRIBE Calling Search Space —
SIP Profile Yes Choose from the following:
• Standard SIP Profile
• Standard BFCP SIP Profile
Information in this field reflects SIP profiles that
have been created on this Unified CM.
See “Configuring the BFCP over UDP
Collaboration Feature” in Chapter 2, “Configuring
Cisco TelePresence Features.”
Digest User —
Check-Boxes
Media Termination point Required — Box is un-checked.
Unattended Port
Require DTMF Reception
Note When you are finished making changes, click Save to save your settings.
