5-4
Cisco Unified Communications Manager Configuration Guide for the Cisco TelePresence System
OL-21851-01
Chapter 5 Configuring and Managing the Cisco Unified IP Phone
Configuring the Cisco Unified IP Phone
Note Assign the same directory number that is assigned to the Cisco TelePresence device to the
Cisco Unified IP Phone 7970 Series.
Note The “Required” column in the table reflects fields marked with an asterisk ( * ) in the administration
interface, which are required entries for basic configuration.
Table 5-1 Cisco Unified IP Phone 7970 Series Device Information
Field Required? Setting
Registration — Read-only. Indicates whether the system is
Registered with Cisco Unified Communications
Manager and lists the registered Unified CM
address.
IP Address — Cisco Unified IP Phone IP address. Click on the IP
address to log into the phone in a new Device
Information window.
Active Load ID — View-only field showing the status of the active
load.
Note Available on the Cisco Unified IP Phone but
not available on the CTS.
Device is active — A green check mark indicates that the device is
active.
Device is trusted — A green check mark indicates that the device is
trusted.
MAC Address Yes MAC address for the Cisco Unified IP Phone 7975.
Description — Short description of the device.
Device Pool Yes Your device pools. Leave field as Default.
Click View Details to open the Device Details
window, which includes the following system
setting information:
• Device Pool Settings
• Roaming Sensitive Settings
• Device Mobility Related Information
• Incoming Calling Party Settings
Common Device Configuration — Your configured devices. Leave field as .
Click Details or View to see the following
information in a new window:
• Common Device Configuration Information
• Multilevel Precedence and Preemption
Information
