Powering Up the Avaya C360
58 Installation and Configuration Guide Avaya C360 Multilayer Stackable Switches, version 4.5
Post-Installation
The following indicate that you have performed the installation procedure correctly:
If you do not receive the appropriate indication, please refer to Chapter 12: Troubleshooting the
Installation .
Table 12: Post-Installation Indications
Procedure Indication Troubleshooting
Information
Powering the
C360 ● All front panel function LEDs
illuminate briefly.
- If the PWR LED blinks once every 1
second, then the BUPS is active
and the main PSU is down.
● The LINK, SYS and PWR LEDs light
● The port LEDs flash
Switch does not
power up
on
page 201
Creating
stacks The LED next to the appropriate connection
(“Cable to upper unit" or “Cable to lower
unit") is lit. Stacking not
functioning
on
page 203
